ABS-M30i Biocomatible, Sterilizable Material
Material Benefits
Full name: acrylonitrile butadiene styrene – ISO 10993 USP Class VI biocompatible Colours: Ivory Layer Thickness: 0.013 inch (0.330 mm), 0.010 inch (0.254 mm), 0.007 inch (0.178 mm), 0.005 inch (0.127 mm) Support Structure: Soluble Tensile Strength: 5,200 psi (36 MPa) Tensile Elongation: 4.0% Flexural Stress: 8,800 psi (61 MPa) IZOD Impact, notched: 2.6 ft-lb/in (139 J/m) Heat Deflection: 204°F (96°C)
Click to enlarge
ABS-M30i    is    a    high    strength    material    well    suited    for    the    medical,    pharmaceutical    and    food packaging   industries.   Parts   manufactured   with   ABS-M30i   material   are   biocompatible   (ISO   10993 USP   Class   VI)   and   can   be   gamma   or   EtO   sterilized   Using   ABS-M30i   engineers   and   designers   can produce surgical planning models, tools and fixtures in-house, directly from CAD data.
Material Properties
Biocompatible     (ISO     10993     USP     Class     VI     )1 material.    Sterilizable    using    gamma    radiation    or ethylene   oxide   (EtO)   sterilization   methods.   Best fit   for   applications   requiring   good   strength   and sterilization.     Creates     realistic     functional     tests parts which can also be used for end use.
