PC Strong Engineering Thermoplastic
Full name: polycarbonate Colours: white Layer Thickness: 0.013 inch (0.330 mm), 0.010 inch (0.254 mm), and 0.007 inch (0.178 mm) Support Structure: BASS, Soluble Tensile Strength: 9,800 psi (68 MPa) Tensile Elongation: 6.0% Flexural Stress: 15,100 psi (104 MPa) IZOD Impact, notched: 1.0 ft-lb/in (53 J/m) Heat Deflection: 280°F (138°C)
Click to enlarge
A   true   industrial   thermoplastic,   PC   (polycarbonate)   is   widely   used   in   automotive,   aerospace,   medical and   many   other   applications.   PC   offers   accuracy,   durability   and   stability,   creating   strong   parts   that withstand   functional   testing.   PC   part   is   5-60   percent   stronger   than   a   part   made   on   previous   FDM systems. It also has superior mechanical properties to ABS and a number of other thermoplastics
Material Benefits
Material Properties
Biocompatible   (ISO   10993   USP   Class   VI   )   material. Ideal   for   demanding   prototyping   needs,   tooling and   fixtures,   and   patterns   for   metal   bending   and composite      work.      Sterilizable      using      gamma radiation    or    ethylene    oxide    (EtO)    sterilization methods.Best   fit   for   applications   requiring   higher strength   and   sterilization.   Breakaway   or   soluble support materials are available for PC.
Data Sheet Download
Eee Tee Digital Design Limited
Industrial 3D Printing Services
Form Fit and Function End Use Parts
(403) 297-9793
(888) 297-9793
PC Strong Engineering Thermoplastic
Full name: polycarbonate Colours: white Layer Thickness: 0.013 inch (0.330 mm), 0.010 inch (0.254 mm), and 0.007 inch (0.178 mm) Support Structure: BASS, Soluble Tensile Strength: 9,800 psi (68 MPa) Tensile Elongation: 6.0% Flexural Stress: 15,100 psi (104 MPa) IZOD Impact, notched: 1.0 ft-lb/in (53 J/m) Heat Deflection: 280°F (138°C)
Click to enlarge
A    true    industrial    thermoplastic,    PC    (polycarbonate)    is    widely    used    in automotive,    aerospace,    medical    and    many    other    applications.    PC    offers accuracy,    durability    and    stability,    creating    strong    parts    that    withstand functional   testing.   PC   part   is   5-60   percent   stronger   than   a   part   made   on previous   FDM   systems.   It   also   has   superior   mechanical   properties   to   ABS   and a number of other thermoplastics
Material Benefits
Material Properties
Biocompatible       (ISO       10993 USP   Class   VI   )   material.   Ideal for     demanding     prototyping needs,    tooling    and    fixtures, and       patterns       for       metal bending   and   composite   work. Sterilizable       using       gamma radiation     or     ethylene     oxide (EtO)                          sterilization methods.Best            fit            for applications    requiring    higher strength       and       sterilization. Breakaway   or   soluble   support materials are available for PC.
Data Sheet Download
